Video & Audio
Image Sensor
1/2.5" CMOS Sensor
Video Resolution
Default: 2560 x 2560 (6.5 Megapixels)@25fps
Lens
f=1.98mm F=2.0
Video Format
H.265
Field of View
Horizontal: 180° ; Vertical: 180° ; Diagonal: 180°
Day & Night
IR-cut filter with auto-switching
Infrared Night Vision
Up to 8 Meters (26 ft); LED: 3pcs/850nm
Audio
Two-Way Audio
Power
POE
IEEE 802.3af, 48V Active
DC Power
DC 12.0V⎓1A, <12W
Interface
Power
DC power port
System
Reset Button
Ethernet
One 10M/100Mbps RJ45
Storage
microSD card slot (Max. 256GB)
Audio
Built-in Microphone&Speaker
Software Features
Frame Rate
• Mainstream: 2fps - 25fps(default: 25fps)
• Substream: 4fps - 15fps(default: 10fps)
Code Rate
• Mainstream: 4096Kbps-8192Kbps(default: 6144Kbps)
• Substream: 64Kbps - 512Kbps(default: 256Kbps)
Browser Supported
Edge, Chrome, Firefox, Safari
OS Supported
PC: Windows, Mac OS; Smartphone: iOS, Android
Smart Alarm
Motion Detection/Person Detection
Record Mode
Motion Recording (Default); Scheduled Record; 24/7 Recording
Protocols & Standards
HTTPS, SSL, TCP/IP, UDP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Maximal User Access
20 Users (1 admin account & 19 user accounts); Support up to 12 simultaneous video streams (10 substreams & 2 mainstreams)
Work with
Google Assistant
Working Environment
Temperature
Operating Temperature: -10°C~+55°C (14°F~131°F)
Humidity
Operating Humidity: 10% ~ 90%
