Technical Specifications:
The image sensor is a 1/3" CMOS.
The maximum resolution is 2880 (H) x 1620 (V).
The electronic shutter speed is adjustable from Auto/Manual 1/3 s to 1/100,000 s.
The IR illumination distance is up to 10 meters (32.81 ft).
Illuminator On/Off Control is set to Auto.
It is equipped with 1 IR LED.
The angle adjustment range is Pan: 0° to 355° and Tilt: –5° to 80°.
The maximum aperture is F2.0.
The field of view is H: 74°, V: 41°, and D: 88°.
It supports Human Detection.
The video compression format is H.265.
The video frame rate for the main stream is 2880 x 1620 at 1-25/30 fps.
The sub stream frame rate is 640 x 360 at 1-25/30 fps.
Supported resolutions are 5M (2880 x 1620) and nHD (640 x 360).
The video bit rate for H.265 is 80 kbps to 4096 kbps.
Day/Night mode can be set to Auto(ICR), Color, or B/W.
It features DWDR (Digital Wide Dynamic Range).
It supports Motion Detection.
Image rotation can be set to 0° or 180°.
It has a built-in MIC.
It has a built-in speaker.
The audio compression format is G.711a.
The network port is an RJ-45 (10/100 Base-T).
It supports Wi-Fi standards IEEE 802.11b/g/n/ax on the 2.4G band (2.412-2.472 GHz) with 20dBm output.
Storage is supported via a Micro SD card, with a capacity of up to 256 GB.
The management software is DMSS.
The mobile client supports iOS and Android.
The power supply is 5 VDC.
Power consumption is 1.9 W in basic mode and 4 W maximum with live view, IR, and PT rotation active.
The operating temperature range is –10 °C to +45 °C (+14 °F to +113 °F).
The operating humidity is less than 95% (RH), non-condensing.
The casing material is plastic.
The product dimensions are D 77.8 mm x 108.1 mm (D 3.06" x 4.26").
The net weight is 195 g (0.30 lb).
