Camera |
|||||
|
Image Sensor |
1/2.9" CMOS |
||||
|
Max. Resolution |
2688 (H) x 1520 (V) |
||||
|
ROM |
128 MB |
||||
|
RAM |
128 MB |
||||
|
Scanning System |
Progressive |
||||
|
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
||||
|
Min. Illumination |
0.006 lux@F1.5 (Color, 30 IRE) 0.0006 lux@F1.5 (B/W, 30 IRE) 0 lux (Illuminator on) |
||||
|
S/N Ratio |
>56 dB |
||||
|
Illumination Distance |
Up to 40 m (131.23 ft) (IR) Up to 40 m (131.23 ft) (Warm light) |
||||
|
Illuminator On/Off Control |
Auto;Manual |
||||
|
Illuminator Number |
2 (Multi-core (IR + warm) light) |
||||
|
Angle Adjustment |
Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° |
||||
|
Lens |
|||||
|
Lens Type |
Motorized vari-focal |
||||
|
Lens Mount |
?14 |
||||
|
Focal Length |
2.7 mm–13.5 mm |
||||
|
Max. Aperture |
F1.5 |
||||
|
Field of View |
H: 97°–28°; V: 52°–16°; D: 117°–32° |
||||
|
Iris Control |
Fixed |
||||
|
Close Focus Distance |
0.8 m (2.62 ft) |
||||
|
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
|
2.7 mm–13.5 mm |
210.0 m( 209.97 ft) |
84.0 m( 83.99 ft) |
42.0 m( 41.99 ft) |
21.0 m ( 20.99 ft) |
|
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. | |||||
|
Intelligence |
|||||
|
IVS (Perimeter Protection) |
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
||||
|
SMD |
SMD Plus |
||||
|
Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
||||
|
Video |
|||||
|
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
||||
|
Smart Codec |
Smart H.265+; Smart H.264+ |
||||
|
Video Frame Rate |
Main stream: 2688 x 1520@(1–20 fps )/2560 x 1440@ (1–25/30 fps) sub stream: 704 x 576@(1–25 fps)/704 x 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
||||
|
Stream Capability |
2 streams |
||||
|
Resolution |
4M (2688 x 1520/2560 x 1440); 3M (2304 x 1296); 1080p (1920 x 1080); 1.3M (1280 x 960); 720p (1280 x 720); D1 (704 x 576/704 x 480); VGA (640 x 480); CIF (352 x 288/352 x 240) |
||||
|
Bit Rate Control |
VBR;CBR |
||||
|
Video Bit Rate |
H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps |
||||
|
Day/Night |
Auto(ICR)/Color/B/W |
||||
|
BLC |
Yes |
||||
|
HLC |
Yes |
||||
|
WDR |
120 dB |
||||
|
White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
||||
|
Gain Control |
Auto/Manual |
||||
|
Noise Reduction |
3D NR |
||||
|
Motion Detection |
OFF/ON (4 areas, rectangular) |
||||
|
Region of Interest (RoI) |
Yes (4 areas) |
||||
|
Smart Illumination |
Yes |
||||
|
Smart Dual Light |
Yes |
||||
|
Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 2688 x 1520 resolution and lower) |
||||
|
Mirror |
Yes |
||||
|
Privacy Masking |
4 areas |
||||
|
Audio |
|||||
|
Built-in MIC |
Yes, built-in Mic |
||||
|
Audio Compression |
G.711a; G.711Mu; G.726; PCM |
||||
|
Alarm |
|||||
|
Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; defocus detection; SMD; security exception |
||||
|
Network |
|||||
|
Network Port |
RJ-45 (10/100 Base-T) |
||||
|
Network Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P |
||||
|
Interoperability |
ONVIF (Profile S & Profile T & Profile G); CGI |
||||
|
User/Host |
6 (Total bandwidth: 36 M) |
||||
|
Storage |
FTP; SFTP; Micro SD card (support max. 256 GB) |
||||
|
Browser |
IE Chrome Firefox |
||||
|
Management Software |
Smart PSS Lite; DSS; DMSS; DoLynk Care |
||||
|
Mobile Client |
iOS;Android |
||||
|
Cyber Security |
Video encryption;Configuration encryption;Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509 certification;syslog;HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade |
||||
|
Certification |
|||||
|
Certifications |
CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
||||
|
Power |
|||||
|
Power Supply |
12 VDC; PoE (802.3af) |
||||
|
Power Consumption |
Basic: 2.3 W (12 VDC), 2.8 W (PoE); Max.: 7.8 W (12 VDC), 9.3 W (PoE) (H.265 + intelligence on+ WDR + warm light intensity) |
||||
|
Environment |
|||||
|
Operating Temperature |
–30 °C to +60 °C (–22 °F to +140 °F) |
||||
|
Operating Humidity |
?95% (RH), non-condensing |
||||
|
Storage Temperature |
–30 °C to +60 °C (–22 °F to +140 °F) |
||||
|
Storage Humidity |
?95% (RH), non-condensing |
||||
|
Protection |
IP67 |
||||
|
Structure |
|||||
|
Casing Material |
Metal |
||||
|
Product Dimensions |
108.3 mm x ?122 mm (4.26" x ?4.80") |
||||
|
Net Weight |
0.69 kg (1.52 lb) |
||||
|
Gross Weight |
0.86 kg (1.89 lb) |
