System |
|
|
Main Processor |
Embedded Processor |
|
Button Type |
Mechanical |
|
Basic |
|
|
Camera |
1/2.8" 2 MP CMOS HDR Camera |
|
Field of View |
H: 84°; V: 43°; D: 99° |
|
WDR |
DWDR |
|
Noise Reduction |
3D NR |
|
Video Resolution |
P: 960 (H) × 576 (V) |
|
Video Frame Rate |
P: 25 fps |
|
Light Compensation |
Auto IR |
|
Day/Night |
Auto(ICR)/Color/B/W |
|
Audio Input |
1 channel |
|
Audio Output |
Built-in speaker |
|
Audio Mode |
Two-way audio (half–duplex) |
|
Function |
|
|
Unlock Mode |
IC card; password; remote unlock |
|
Card Type |
IC card |
|
Leave Videos |
Yes (SD card inserted in VTH is needed) |
|
Performance |
|
|
Card Reading Distance |
0 cm-2 cm |
|
Issue Card Locally |
Yes |
|
Casing Material |
Aluminum alloy |
|
Capacity |
|
|
Card Capacity |
100 |
|
Port |
|
|
RS-485 |
1 |
|
Alarm Output |
1 |
|
Power Output |
1 (12 V, 500 mA) |
|
Exit Button |
1 |
|
Door Status Detection |
1 |
|
Lock Control |
1 |
|
Alarm |
|
|
Tamper Alarm |
Yes |
|
General |
|
|
Unlock Password Mode |
Personal password |
|
Appearance Color |
Silvery white |
|
Power Supply |
2-wire Controller |
|
Power Adapter |
Optional |
|
Installation |
Surface Mount |
|
Certifications |
CE |
|
Accessory |
Sold separately: 2-wire controller |
|
Product Dimensions |
205.8 mm × 85.3 mm × 46.5 mm (8.10" × 3.36" × 1.83") |
|
Protection |
IP65 IK08 |
|
Operating Temperature |
–40 °C to +60°C (–40 °F to +140 °F) |
|
Operating Humidity |
10%–90% (RH), non-condensing |
|
Operating Environment |
Outdoor |
|
Operating Altitude |
0 m–3000 m (0 ft – 9842.52 ft) |
|
Power Consumption |
? 2 W (standby), ? 12 W (working) |
|
Gross Weight |
978 g (2.16 lb) |
|
Anti-corrosion Level |
Basic Protection |
