| System | |
| Main Processor | Embedded processor |
| Operating System | Embedded Linux operating system |
| Network Protocol | RTSP; RTP; SIP; DNS; SSH |
| Basic | |
| Screen Type | Capacitive Touchscreen |
| Display | 10" TFT |
| Screen Resolution | 1024 × 600 |
| Audio Compression | G.711a; G.711u; PCM |
| Audio Input | 1 |
| Audio Output | Built-in speaker |
| Audio Mode | 2-way Audio |
| Audio Enhancement | Echo suppression |
| Audio Bit Rate | 16 kHz; 16 Bit |
| Function | |
| Communication Mode | Full digital |
| Information Release | Receive and view text information released by the management center |
| DND Mode | Do not disturb period can be set; Do not disturb mode |
| Number of Extensions | Villa: 9 Apartment: 4 |
| Wi-Fi | Yes |
| Wireless Standard | IEEE802.11b/802.11g/802.11n |
| Wireless Frequency Range | 2.4 GHz |
| Wireless Security Encryption | WPA/WPA2; WPA-PSK/WPA2-PSK |
| Storage | Micro SD card (up to 64 GB) |
| Performance | |
| Casing | Metal |
| Alarm | |
| SOS | Yes |
| Port | |
| Alarm Input | 6 |
| Alarm Output | 1 |
| Door Bell | Yes (use any alarm input port) |
| Network | One 10 /100 Mbps Ethernet |
| General | |
| Color | Siliver |
| Power Supply | 12 VDC 1A Standard PoE (36–57 V, 0.35 A) |
| Installation | Surface Mount |
| Certifications | CE; FCC |
| Accessory | Bracket and alarm ribbon cable (included) |
| Dimensions | 250 mm × 190 mm × 23.5 mm (9.84" × 7.48" × 0.93") |
| Operating Temperature | –10 °C to +55 °C (+14 °F to 131 °F) |
| Operating Humidity | 10%–95% RH (non-condensing) |
| Operating Altitude | Beneath 3,000 m (9,842.52 ft) |
| Power Consumption | Standby ? 3W; working ? 7W |
| Net Weight | 0.67 kg (1.47 lb) |
| Gross Weight | 0.85 kg (1.87 lb) |
