System |
|
|
Main Processor |
Embedded processor |
|
Operating System |
Embedded Linux operating system |
|
Interoperability |
ONVIF |
|
Network Protocol |
SIP; IPv4; RTSP; RTP; TCP; UDP |
|
Basic |
|
|
Screen Type |
Capacitive touch screen |
|
Display |
7" TFT |
|
Screen Resolution |
1024 x 600 |
|
Audio Compression |
G.711a; G.711Mu; G.711u; PCM |
|
Audio Input |
1 |
|
Audio Output |
Built-in speaker |
|
Audio Mode |
Two-way audio |
|
Audio Enhancement |
Echo suppression |
|
Audio Bit Rate |
16 KHz, 16Bit |
|
Function |
|
|
Communication Mode |
Full digital |
|
Information Release |
Receive and view text information released by the management center (After SD card is installed, picture information can be received and viewed.) |
|
Leave Videos |
Yes (insert an SD card into the indoor monitor) |
|
DND Mode |
DND period and DND mode can be set. |
|
Number of Extension |
Villa: 10; apartment: 6 |
|
Storage |
Micro SD card (up to 64 GB) |
|
Performance |
|
|
Casing |
PC + ABS |
|
Port |
|
|
RS-485 |
1 |
|
Alarm Input |
6 |
|
Alarm Output |
1 |
|
Power Output |
1 (12V/100mA) |
|
Door Bell |
Yes (use any alarm input port) |
|
Network |
One 10 Mbps/100 Mbps Ethernet |
|
General |
|
|
Color |
Black or white |
|
Power Supply |
12V DC 1A |
|
Power Adapter |
Not included |
|
Installation |
Surface mount |
|
Certifications |
CE; FCC; UL |
|
Accessory |
Bracket and alarm ribbon cable (included) |
|
Dimensions |
189.0 mm x 130.0 mm x 26.9 mm (7.44" x 5.12" x 1.06") |
|
Operating Temperature |
-10°C to +55°C (+14°F to 131°F) |
|
Operating Humidity |
20% to 93% (non-condensing) |
|
Operating Altitude |
Beneath 3000 m (9842.52 ft) |
|
Power Consumption |
Standby ? 2W; working ? 6W |
|
Net Weight |
384 g (0.85 lb) |
|
Gross Weight |
737 g (1.62 lb) |
