| System | |
| Main Processor | Embedded processor |
| Operating System | Embedded Linux operating system |
| Network Protocol | IPv4; FTP; UPnP; SNMP; DNS; DDNS; RTSP; RTP; TCP; UDP; SIP |
| Basic | |
| Screen Type | Capacitive Touchscreen |
| Display | 7" TFT |
| Screen Resolution | 1024 × 600 |
| Audio Compression | G.711a; G.711u; PCM |
| Audio Input | 1 |
| Audio Output | Built-in speaker |
| Audio Mode | 2-way voice communication |
| Audio Enhancement | Echo suppression |
| Audio Bit Rate | 16 kHz; 16 Bit |
| Function | |
| Communication Mode | Full digital |
| Information Release | Receive and view text information released by the management center |
| DND Mode | Do not disturb period can be set; Do not disturb mode |
| Number of Extensions | Villa: 9 Apartment: 4 |
| Wi-Fi | Yes |
| Wireless Standard | IEEE802.11b/802.11g/802.11n |
| Wireless Frequency Range | 2.4 GHz |
| Performance | |
| Casing | PC + ABS |
| Port | |
| Alarm Input | 6 |
| Alarm Output | 1 |
| Power Output | 1 (12 V/200 mA) |
| Door Bell | Yes (use any alarm input port) |
| Network | One 10 /100 Mbps Ethernet |
| Network | One 10 Mbps/100 Mbps Ethernet |
| Alarm | |
| SOS | Yes |
| General | |
| Color | White |
| Power Supply | 12 VDC 1A; Standard PoE (36–57 V, 0.35 A) |
| Installation | Surface Mount |
| Certifications | CE; FCC |
| Accessory | Bracket and alarm ribbon cable (included) |
| Dimensions | 189.6 mm × 134.6 mm × 26.0 mm (7.50" × 5.30" × 1.00") |
| Operating Temperature | –10 °C to +55 °C (+14 °F to 131 °F) |
| Operating Humidity | 10%–95% RH (non-condensing) |
| Operating Altitude | Beneath 3,000 m (9,842.52 ft) |
| Power Consumption | Standby ? 2W; working ? 6W |
| Net Weight | 335 g (0.74 lb) |
| Gross Weight | 575 g (1.27 lb) |
| Gross Weight | 575 g (1.27 lb) |
